Lọc máy nén khí Atlascopco
HÃNG ATLAS COPCO
Model Series: GA/GAU/GR/GX | Z-Series | Portable (XA/XAS)
GA/GAU/GR/GX Series Models
• * - For Compressors with Serial #'s 776549 and Above
• ** - For Compressors with Serial #'s 310000 and Below
| Model | Serial # | Air Filter | Oil Filter | Separator |
| GA5 | 1503-0190-00 | 1513-0337-00 | 1513-0058-00 | |
| GA5 | From 1998 | 1613-9001-00 | 1613-6105-00 | 2901-0523-00 |
| GA5 | From 119500 | 1613-9001-00 | 1613-6105-00 | 1613-9014-00 |
| GA5 | From 145000 | 1613-9001-00 | 2903-0337-00 | 2901-0523-00 |
| GA5 C | From 130000 | 1613-9001-00 | 1613-6105-00 | 1613-9014-00 |
| GA5 C | From 145000 | 1613-9001-00 | 1513-0337-00 | 2903-0871-00 |
| GA5 VSD | From 700000 | 1613-9001-00 | 2202-9295-50 | 2202-9294-50 |
| GA7 | 1503-0190-00 | 1513-0337-00 | 1513-0058-00 | |
| GA7 | From 119500 | 1613-9001-00 | 1613-6105-00 | 1613-9014-00 |
| GA7 | From 145000 | 1613-9001-00 | 2903-0337-00 | 2901-0523-00 |
| GA7 C | From 130000 | 1613-9001-00 | 1613-6105-00 | 1613-9014-00 |
| GA7 C | From 145000 | 1613-9001-00 | 1513-0337-00 | 2903-0871-00 |
| GA7 VSD | From 700000 | 1613-9001-00 | 2202-9295-50 | 2202-9294-50 |
| GA10 | 1503-0190-00 | 1513-0337-00 | 1513-0058-00 | |
| GA10 | From 119500 | 1613-9001-00 | 1613-6105-00 | 1613-9014-00 |
| GA10 | From 145000 | 1613-9001-00 | 2903-0337-00 | 2901-0523-00 |
| GA11 | 1619-1269-00 | 1613-6105-00 | 1612-3869-00 | |
| GA11 | From 1993 | 1619-1269-00 | 1613-6105-00 | 1613-6921-00 |
| GA11 | 1994 Up To 217791 | 2903-1012-00 | 1613-6105-00 | 2901-0004-01 |
| GA11 | 1995 From 217792 | 2903-1012-00 | 1613-6105-00 | 2901-0343-00 |
| GA11 | From 246349 | 1613-8720-00 | 1613-6105-00 | 1613-7502-00 |
| GA11 C | 1613-9001-00 | 1613-6105-00 | 1613-7502-00 | |
| GA11 C | From 119500 | 1613-9001-00 | 1613-6105-00 | 1613-9014-00 |
| GA11 C | From 145000 | 1613-9001-00 | 1513-0337-00 | 2903-0871-00 |
| GA11 C | From 255000 | 1613-8720-00 | 1613-6105-00 | 2901-0779-00 |
| GA11 C | From 268500 | 1613-8720-00 | 1613-6105-00 | 2901-0779-01 |
| GA11 PLUS | From 810000 | 1613-8720-00 | 1622-7836-00 | 2901-1963-00 |
| GA11 VSD | From 700000 | 1613-9001-00 | 2202-9295-50 | 2202-9294-50 |
| GA15 | 1619-1269-00 | 1613-6105-00 | 1612-3869-00 | |
| GA15 | From 1993 | 1619-1269-00 | 1613-6105-00 | 1613-6921-00 |
| GA15 | 1994 Up To 217791 | 2903-1012-00 | 1613-6105-00 | 2901-0004-01 |
| GA15 | 1995 From 217792 | 2903-1012-00 | 1613-6105-00 | 2901-0343-00 |
| GA15 | From 2000 | 1613-8720-00 | 1613-6105-00 | 1619-9720-00 |
| GA15 | From 246349 | 1613-8720-00 | 1613-6105-00 | 1613-7502-00 |
| GA15 C | From 255000 | 1613-8720-00 | 1613-6105-00 | 2901-0779-00 |
| GA15 C | From 268500 | 1613-8720-00 | 1613-6105-00 | 2901-0779-01 |
| GA15 PLUS | From 810000 | 1613-8720-00 | 1622-7836-00 | 2901-1963-00 |
| GA15 VSD | From 700000 | 1613-8720-00 | 2202-9295-50 | 2202-9294-50 |
| GA18 | 1619-1269-00 | 1613-6105-00 | 1612-3869-00 | |
| GA18 | From 1993 | 1619-1269-00 | 1613-6105-00 | 1613-6921-00 |
| GA18 | 1994 Up To 217791 | 2903-1012-00 | 1613-6105-00 | 2901-0004-01 |
| GA18 | 1995 From 217792 | 2903-1012-00 | 1613-6105-00 | 2901-0343-00 |
| GA18 | From 2000 | 1613-8720-00 | 1613-6105-00 | 1619-9720-00 |
| GA18 | From 246349 | 1613-8720-00 | 1613-6105-00 | 1613-7502-00 |
| GA18 C | From 255000 | 1613-8720-00 | 1613-6105-00 | 2901-0779-00 |
| GA18 C | From 268500 | 1613-8720-00 | 1613-6105-00 | 2901-0779-01 |
| GA18 VSD | 1613-8720-00 | 1613-6105-00 | 1622-0516-00 | |
| GA18 PLUS | From 810000 | 1613-8720-00 | 1622-7836-00 | 2901-1963-00 |
| GA22 | 1619-1269-00 | 1613-6105-00 | 1612-3869-00 | |
| GA22 | From 1993 | 1619-1269-00 | 1613-6105-00 | 1613-6921-00 |
| GA22 | 1994 Up To 217791 | 2903-1012-00 | 1613-6105-00 | 2901-0004-01 |
| GA22 | 1995 From 217792 | 2903-1012-00 | 1613-6105-00 | 2901-0343-00 |
| GA22 | From 2000 | 1613-8720-00 | 1613-6105-00 | 1619-9720-00 |
| GA22 | From 246349 | 1613-8720-00 | 1613-6105-00 | 1613-7502-00 |
| GA22 C | From 255000 | 1613-8720-00 | 1613-6105-00 | 2901-0779-00 |
| GA22 C | From 268500 | 1613-8720-00 | 1613-6105-00 | 2901-0779-01 |
| GA22 PLUS | From 268500 | 1613-8720-00 | 1613-6105-00 | 2901-0779-01 |
| GA22 PLUS | From 810000 | 1613-8720-00 | 1622-7836-00 | 2901-1963-00 |
| GA22 VSD | 297500-420963 | 1613-8720-00 | 1613-6105-00 | 1622-0516-00 |
| GA26 PLUS | From 810000 | 1613-8720-00 | 1622-7836-00 | 2901-1963-00 |
| GA30 | 1619-2997-00 | 1613-6105-00 | 1202-6414-00 | |
| GA30 | From 1994 | 1613-7407-00 | 1613-6105-00 | 1613-6880-00 |
| GA30 | 1994 Up To 315329 | 1619-2997-00 | 1613-6105-00 | 2901-0213-00 |
| GA30 | From 315330 | 1613-7407-00 | 1613-6105-00 | 2901-0213-00 |
| GA30 | 1998 From 360000 | 1613-7407-00 | 1613-6105-00 | 2901-0566-00 |
| GA30 | From 810000 | 1613-8720-00 | 1622-7836-00 | 2901-1963-00 |
| GA30 C | From 2000 | 1613-8720-00 | 1613-6105-00 | 1619-9720-00 |
| GA30 C | From 255000 | 1613-8720-00 | 1613-6105-00 | 2901-0779-00 |
| GA30 C | From 268500 | 1613-8720-00 | 1613-6105-00 | 2901-0779-01 |
| GA30 PLUS | From 507438 | 1613-7408-00 | 1622-3142-80 or 1622-5072-80 | 2901-1626-00 |
| GA30 PLUS | 2006 From 591000 | 1613-7407-00 | 1622-3142-80 or 1622-5072-80 | 2901-1643-00 |
| GA30 VSD | 1613-7408-00 | 1613-6105-00 | 1613-8397-00 | |
| GA37 | 1619-2997-00 | 1613-6105-00 | 1202-6414-00 | |
| GA37 | From 1994 | 1613-7407-00 | 1613-6105-00 | 1613-6880-00 |
| GA37 | 1994 Up To 315329 | 1619-2997-00 | 1613-6105-00 | 2901-0213-00 |
| GA37 | From 315330 | 1613-7407-00 | 1613-6105-00 | 2901-0213-00 |
| GA37 | 1998 From 360000 | 1613-7407-00 | 1613-6105-00 | 2901-0566-00 |
| GA37 | 2006 From 591000 | 1613-7407-00 | 1622-3142-80 or 1622-5072-80 | 2901-1643-00 |
| GA37 - 7.5 Bar | 1613-7408-00 | 1613-6105-00 | 1613-8397-00 | |
| GA37 - 10 Bar | 1613-7407-00 | 1613-6105-00 | 2901-1389-00 | |
| GA37 - 13 Bar | 1613-7407-00 | 1613-6105-00 | 2901-0566-00 | |
| GA37 PLUS | From 507438 | 1613-7408-00 | 1622-3142-80 or 1622-5072-80 | 2901-1626-00 |
| GA37 VSD | 1613-7408-00 | 1613-6105-00 | 1613-8397-00 | |
| GA37 VSD | From 572446 | 1613-7408-00 | 1622-3142-80 or 1622-5072-80 | 1622-3140-00 |
| GA45 | 1619-2847-00 | 1613-6105-00 | 1202-7419-00 | |
| GA45 | From 1994 | 1619-2847-00 | 1613-6105-00 | 1613-6880-00 |
| GA45 | From 1995 | 1613-7408-00 | 1613-6105-00 | 1613-7306-00 |
| GA45 | 1994 Up To 315329 | 1619-2847-00 | 1613-6105-00 | 2901-0213-00 |
| GA45 | From 315330 | 1613-7408-00 | 1613-6105-00 | 2901-0213-00 |
| GA45 | 1998 From 360000 | 1613-7408-00 | 1613-6105-00 | 2901-0566-00 |
| GA45 | 2006 From 591000 | 1613-7407-00 | 1622-3142-80 or 1622-5072-80 | 2901-1643-00 |
| GA45 - 7.5 Bar | 1613-7408-00 | 1613-6105-00 | 1613-8397-00 | |
| GA45 - 10 Bar | 1613-7408-00 | 1613-6105-00 | 2901-1389-00 | |
| GA45 - 13 Bar | 1613-7407-00 | 1613-6105-00 | 2901-0566-00 | |
| GA45 PLUS | From 507438 | 1613-7408-00 | 1622-3142-80 or 1622-5072-80 | 2901-1626-00 |
| GA45 VSD | FRom 572446 | 1613-7408-00 | 1622-3142-80 or 1622-5072-80 | 1622-3140-00 |
| GA50 | 1998 From 350000 | 1613-7408-00 | 1613-6105-00 | 2901-0566-00 |
| GA50 VSD | 1613-7408-00 | 1613-6105-00 | 1613-8397-00 | |
| GA55 | 1619-2798-00 | 1613-6105-00 | 1202-7419-00 | |
| GA55 | From 1995 | 1613-7408-00 | 1613-6105-00 | 1613-7306-00 |
| GA55 | 1996 From 460001 | 1613-7408-00 | 1613-6105-00 | 1613-8007-00 |
| GA55 | From 2000 | 1613-9501-00 | 1613-6105-00 | 1613-9559-00 |
| GA55 | From 507438 | 1622-1855-01 | 1622-3142-80 or 1622-5072-80 | 2901-1626-00 |
| GA55 C | 1613-7408-00 | 1613-6105-00 | 1613-8007-00 | |
| GA55 C | From 471000 | 1613-9501-00 | 1613-6105-00 | 1613-9559-00 |
| GA55 PLUS | From 2005 | 1613-9503-00 | 1622-3652-80 or 1622-4601-80 | 2901-0566-22 |
| GA55 VSD | From 572446 | 1622-1855-01 | 1622-3142-80 or 1622-5072-80 | 2901-1626-00 |
| GA75 | 1613-9501-00 | 1613-6105-00 | 1202-7419-00 | |
| GA75 | From 1995 | 1613-7408-00 | 1613-6105-00 | 1613-7306-00 |
| GA75 | 1996 From 460001 | 1613-8004-00 | 1613-6105-00 | 1613-8007-00 |
| GA75 | From 2000 | 1613-9503-00 | 1613-6105-00 | 1613-9840-00 |
| GA75 | From 471000 | 1613-9503-00 | 1613-6105-00 | 2901-0858-00 |
| GA75 | From 507438 | 1622-1855-01 | 1622-3142-80 or 1622-5072-80 | 2901-1626-10 |
| GA75 C | From 474000 | 1613-9503-00 | 1613-6105-00 | 2901-0858-00 |
| GA75 PLUS | From 2005 | 1613-9503-00 | 1622-3652-80 or 1622-4601-80 | 2901-0566-22 |
| GA75 VSD | 1613-9503-00 | 1622-3652-80 or 1622-4601-80 | 1613-9840-00 | |
| GA75 VSD | From 493000 | 1613-9503-00 | 1613-6105-00 | 1613-9559-00 and 1613-7277-00 |
| GA90 | 1030-0979-00 | 1613-6105-00 | 1614-6423-00 | |
| GA90 | 1999 From 056813 | 1621-0547-00 | 1613-6105-00 | 2906-0564-00 |
| GA90 PLUS | From 2005 | 1613-9503-00 | 1622-3652-80 or 1622-4601-80 | 2901-0566-22 |
| GA90 | From 2006 | 1613-9503-00 | 1622-3652-80 or 1622-4601-80 | 2906-0751-00 |
| GA90 - 5.2-5.5 Bar | From 2008 | 1621-7376-00 | 1621-7378-00 | 2906-0956-00 |
| GA90 - 6.9-8.6 Bar | From 2008 | 1621-7376-00 | 1621-7378-00 | 2906-0955-00 |
| GA90 - 10-14 Bar | From 2008 | 1621-7376-00 | 1621-7378-00 | 2906-0954-00 |
| GA90 C | 1613-8004-00 | 1613-6105-00 | 1613-8007-00 | |
| GA90 C | From 474000 | 1613-9503-00 | 1613-6105-00 | 2901-0858-00 |
| GA90 VSD | 1613-9503-00 | 1622-3652-80 or 1622-4601-80 | 2901-0566-22 | |
| GA90 VSD | From 493000 | 1613-9503-00 | 1613-6105-00 | 1613-9559-00 and 1613-7277-00 |
| GA100 | 1619-1269-00 | 1613-6105-00 | 2901-0003-00 | |
| GA110 | 1030-0979-00 | 1613-6105-00 | 1614-6423-00 | |
| GA110 | 1999 From 056813 | 1621-0547-00 | 1613-6105-00 | 2906-0564-00 |
| GA110 | From 2006 | 1621-0547-00 | 1613-6105-00 | 2906-0751-00 |
| GA110 | From 2008 | 1621-7376-00 | 1621-7378-00 | 1623-0515-00 |
| GA110 - 10-14 Bar | From 2008 | 1621-7376-00 | 1621-7378-00 | 1623-0516-00 |
| GA110 PLUS | From 2008 | 1621-7376-00 | 1621-7378-00 | 2906-0955-00 |
| GA110 PLUS 10-14 Bar | From 2008 | 1621-7376-00 | 1621-7378-00 | 2906-0954-00 |
| GA111 up to 122 | 1619-1269-00 | 1613-6105-00 | 1612-3869-00 | |
| GA132 | 1030-0979-00 | 1613-6105-00 | 1614-6423-00 | |
| GA132 | 1999 From 056813 | 1621-0547-00 | 1613-6105-00 | 2906-0565-00 |
| GA132 | From 2006 | 1621-5742-00 | 1613-6105-00 | 2906-0752-00 |
| GA132 - 5.2-5.5 Bar | From 2008 | 1621-7376-00 | 1621-7378-00 | 2906-0956-00 |
| GA132 - 6.9-8.6 Bar | From 2008 | 1621-7376-00 | 1621-7378-00 | 2906-0955-00 |
| GA132 - 10-14 Bar | From 2008 | 1621-7376-00 | 1621-7378-00 | 2906-0954-00 |
| GA160 | 1030-0979-00 | 1613-6105-00 | 1614-6423-00 | |
| GA160 | 1999 From 056813 | 1621-0547-00 | 1613-6105-00 | 2906-0565-00 |
| GA160 | From 2006 | 1621-5742-00 | 1613-6105-00 | 2906-0752-00 |
| GA160 - 5.2-5.5 Bar | From 2008 | 1621-7376-00 | 1621-7378-00 | 2906-0956-00 |
| GA160 - 6.9-8.6 Bar | From 2008 | 1621-7376-00 | 1621-7378-00 | 2906-0955-00 |
| GA160 - 10-14 Bar | From 2008 | 1621-7376-00 | 1621-7378-00 | 2906-0954-00 |
| GA180 VSD | 1621-0547-00 | 1613-6105-00 | 1614-9056-00 | |
| GA180 VSD | From 2006 | 1621-5742-00 | 1613-6105-00 | 2906-0752-00 |
| GA200 | 1030-0979-00 | 1614-7273-00 | 1614-7048-00 | |
| GA200 | From 1999 | 1621-0547-00 | 1613-6105-00 | 1614-9056-00 |
| GA200 | From 2000 | 1621-0547-00 | 1614-7273-00 | 2906-0588-00 |
| GA200 | From 2006 | 1621-5742-00 | 1614-7273-00 | 2906-0753-00 |
| GA200 | From 2008 | 1621-5107-00 | 1614-7273-00 | 1621-9386-00 |
| GA207 up to 210 | 1030-1070-00 | 1613-6105-00 | 1613-2433-00 | |
| GA230 | 1619-2997-00 | 1613-6105-00 | 1614-5329-00 | |
| GA237 | 1619-2997-00 | 1613-6105-00 | 1614-5329-00 | |
| GA250 | 1030-0979-00 | 1614-7273-00 | 1614-7048-00 | |
| GA250 | 1619-2798-00 | 1614-8065-00 | 2906-0588-00 | |
| GA307 up to 310 | 1030-1070-00 | 1613-6105-00 | 1613-2433-00 | |
| GA315 | 1030-0979-00 | 1614-7273-00 | 1614-7048-00 | |
| GA315 | From 2000 | 1621-0547-00 | 1614-7273-00 | 2906-0588-00 |
| GA315 | From 2006 | 1621-5742-00 | 1614-7273-00 | 2906-0753-00 |
| GA315 VSD | 1621-0547-00 | 1614-7273-00 | 2906-0588-00 | |
| GA315 VSD | From 2006 | 1621-5742-00 | 1614-7273-00 | 2906-0753-00 |
| GA345 | 1619-2847-00 | 1613-6105-00 | 1202-8343-00 | |
| GA355 | 1619-2798-00 | 1613-6105-00 | 1202-8343-00 | |
| GA375 | 1619-2798-00 | 1613-6105-00 | 1202-8343-00 | |
| GA407 up to 410 | 1030-1070-00 | 1613-6105-00 | 1613-2433-00 | |
| GA450 | 1621-0547-00 | 1614-7273-00 | 1613-9521-00 | |
| GA450 | From 2006 | 1621-5742-00 | 1613-6105-00 | 2906-0753-00 |
| GA507 up to 510 | 1030-1070-00 | 1613-6105-00 | 2901-0078-00 | |
| GA607 upto 710 | 1030-1070-00 | 1613-6105-00 | 2901-0085-00 | |
| GA807 up to 1110 | 1621-0547-00 | 1613-6105-00 | 2906-0020-00 | |
| GA1207 up to 1410 | 1621-0547-00 | 1613-6105-00 | 2911-0017-00 | |
| GAH 115 | 1619-1269-00 | 1613-6105-00 | 2901-0003-00 | |
| GAH 118 | 1619-1269-00 | 1613-6105-00 | 2901-0003-00 | |
| GAH 122 | 1619-1269-00 | 1613-6105-00 | 2901-0003-00 | |
| GAU15 up to 40 | 1619-1269-00 | 1310-0940-83 | 2901-0003-00 | |
| GAU307 up to 509 | 1030-1070-00 | 1613-6105-00 | 2901-0078-00 | |
| GAU607 up to 709 | 1030-1070-00 | 1613-6105-00 | 2901-0085-00 | |
| GAU807 up to 1409 | 1621-0547-00 | 1613-6105-00 | 2906-0020-00 | |
| GR110 up to 200 | 1621-0547-00 | 1202-8040-00 | 2906-0638-00 | |
| GR110 up to 200 | From 085972 | 1621-0547-00 | 1202-8040-00 | 1621-9387-00 |
| GR620 | 1030-1070-00 | 1202-8040-00 | 2901-0078-00 | |
| GR1120 | 1621-0547-00 | 1202-8040-00 | 2906-0020-00 | |
| GR1520 | 1621-0547-00 | 1202-8040-00 | 2911-0017-00 | |
| GX2 | 1622-0658-00 | 1513-0337-00 | 2903-0623-01 | |
| GX3 | 1622-0658-00 | 1513-0337-00 | 2903-0623-01 | |
| GX4 | 1622-0658-00 | 1513-0337-00 | 2903-0623-01 | |
| GX5 | 1613-9001-00 | 1613-6105-00 | 1622-0245-00 | |
| GX5 | Up to 619999 | 1613-9001-00 | 1513-0337-00 | 2903-0871-00 |
| GX5 | From 620000 | 1613-9001-00 | 1613-6105-00 | 2903-0871-00 |
| GX7 | 1613-9001-00 | 1613-6105-00 | 1622-0245-00 | |
| GX7 | Up to 619999 | 1613-9001-00 | 1513-0337-00 | 2903-0871-00 |
| GX7 | From 620000 | 1613-9001-00 | 1613-6105-00 | 2903-0871-00 |
| GX11 | 1613-9001-00 | 1613-6105-00 | 1622-0245-00 | |
| GX11 | Up to 619999 | 1613-9001-00 | 1513-0337-00 | 2903-0871-00 |
| GX11 | From 620000 | 1613-9001-00 | 1613-6105-00 | 2903-0871-00 |
| GX15 | 1613-8720-00 | 1613-6105-00 | 2903-0351-01 | |
| GX18 | 1613-8720-00 | 1613-6105-00 | 2903-0351-01 | |
| GX22 | 1613-8720-00 | 1613-6105-00 | 2903-0351-01 |
• * - For Compressors with Serial #'s 776549 and Above
• ** - For Compressors with Serial #'s 310000 and Below
Z-Series Models:
• * - If Compressor Has Spin-On Type Oil Filter, Replacement Part # is 1613-6105-00
| Model | Air Filter | Oil Filter | 4000 HR Kit | 8000 HR Kit |
| ZA3 | 1030-1070-00 | 1619-0355-00 | 2906-0278-00 | 2906-0279-00 |
| ZA4 | 1030-0979-00 | 1619-0355-00* | 2906-0270-00 | 2906-0271-00 |
| ZA5 | 1030-0979-00 | 1613-6105-00 | 2906-0258-00 | 2906-0264-00 |
| ZA6 | 1030-0979-00 | 1613-6105-00 | 2906-0258-00 | 2906-0259-00 |
| ZR3 | 1030-1070-00 | 1619-0355-00 | 2906-0111-00 | 2906-0112-00 |
| ZR4 | 1030-0979-00 | 1619-0355-00* | 2906-0084-00 | 2906-0085-00 |
| ZR5 | 1030-0979-00 | 1613-6105-00 | 2906-0149-00 | 2906-0150-00 |
| ZR6 | 1030-0979-00 | 1613-6105-00 | 2906-0135-00 | 2906-0136-00 |
| ZR45 | 2900-0582-00 | 1619-6227-00 | 2906-0194-00 | N/A |
| ZR55 | 2900-0582-00 | 1619-6227-00 | 2906-0194-00 | N/A |
| ZR75 | 1619-2799-00 | 1619-6227-00 | N/A | N/A |
| ZR90 | 1619-2799-00 | 1619-6227-00 | N/A | N/A |
| ZR110 | 1030-0979-00 | 1621-0270-00 | N/A | N/A |
| ZR132 | 1030-0979-00 | 1621-0270-00 | N/A | N/A |
| ZR145 | 1030-0979-00 | 1621-0270-00 | N/A | N/A |
| ZR160 | 1621-0094-00 | 1621-0270-00 | N/A | N/A |
| ZR200 | 1621-0094-00 | 1621-0270-00 | N/A | N/A |
| ZR250 | 1621-0094-00 | 1621-0270-00 | N/A | N/A |
| ZR275 | 1621-0094-00 | 1621-0270-00 | N/A | N/A |
| ZR450 | 1621-0094-00 | 1621-0270-00 | N/A | N/A |
| ZR500 | 1621-0094-00 | 1621-0270-00 | N/A | N/A |
| ZR630 | 1621-0094-00 | 1621-0270-00 | N/A | N/A |
| ZR750 | 1621-0094-00 | 1621-0270-00 | N/A | N/A |
| ZT3 | 1030-1070-00 | 1619-0355-00 | N/A | N/A |
| ZT4 | 1030-0979-00 | 1619-0355-00* | N/A | N/A |
| ZT45 | 2900-0582-00 | 1619-6227-00 | 2906-0194-00 | N/A |
| ZT55 | 2900-0582-00 | 1619-6227-00 | 2906-0194-00 | N/A |
| ZT75 | 1619-2799-00 | 1619-6227-00 | N/A | N/A |
| ZT90 | 1619-2799-00 | 1619-6227-00 | N/A | N/A |
| ZT237 | 2900-0582-00 | 1619-6227-00 | N/A | N/A |
| ZT245 | 2900-0582-00 | 1619-6227-00 | N/A | N/A |
| ZT255 | 2900-0582-00 | 1619-6227-00 | N/A | N/A |
| ZT275 | 2900-0582-00 | 1619-6227-00 | N/A | N/A |
| ZT290 | 2900-0582-00 | 1619-6227-00 | N/A | N/A |
• * - If Compressor Has Spin-On Type Oil Filter, Replacement Part # is 1613-6105-00
Portable Models (XA/XAS):
• * - Sump Tank Varies on these Models, Please Consult Dealer for Original Separator Part # Supplied
| Model | Air Filter | Oil Filter | Separator |
| XA 30 | 2900-0593-00 | 1613-6105-00 | 2911-0012-00 |
| XA 35 | 2900-0593-00 | 1613-6105-00 | 2911-0014-00 |
| XA 40 | 2900-0593-00 | 1613-6105-00 | 2911-0013-00 |
| XA 40 D | 2900-0593-00 | 1613-6105-00 | 1619-5498-00 |
| XA 45 | 2900-0593-00 | 1613-6105-00 | 2911-0014-00 |
| XA 50 | 1619-2997-00 | 1613-6105-00 | 2911-0013-00 |
| XA 50 D | 1619-2997-00 | 1613-6105-00 | 1619-5498-00 |
| XA 55 | 1619-2997-00 | 1613-6105-00 | 2911-0014-00 |
| XA 60 | 1619-2847-00 | 1613-6105-00 | 2911-0013-00 |
| XA 65 | 1619-2847-00 | 1613-6105-00 | 2911-0014-00 |
| XA 70 | 1619-2847-00 | 1613-6105-00 | 2911-0014-00 |
| XA 75 | 1619-2847-00 | 1613-6105-00 | 2911-0015-00 |
| XA 80 | 1619-2847-00 | 1613-6105-00 | 2901-0078-00 |
| XA 85 | 1619-2847-00 | 1613-6105-00 | 2911-0015-00 |
| XA 90 | 1619-2847-00 | 1613-6105-00 | 2911-0015-00 |
| XA 120 | 1619-2798-00 | 1613-6105-00 | 2901-0085-00 |
| XA 125 | 1619-2798-00 | 1613-6105-00 | 2911-0016-00 |
| XA 125 D | 1619-2799-00 | 1613-6105-00 | 1616-4656-00 |
| XA 160 | 1619-2799-00 | 1613-6105-00 | 2901-0085-00 |
| XA 175 | 1619-2798-00 | 1613-6105-00 | 2911-0016-00 |
| XA 175 D | 1619-2799-00 | 1613-6105-00 | 1616-4656-00 |
| XA 210 | 1619-2798-00 | 1613-6105-00 | 2911-0021-00 |
| XA 210 D | 1619-2798-00 | 1613-6105-00 | 2252-6313-01 |
| XA 250 | 1619-2798-00 | 1613-6105-00 | 2901-0085-00 |
| XA 350 | 1619-2798-00 | 1613-6105-00 | 2911-0017-00 |
| XA 350 D | 1619-2798-00 | 1613-6105-00 | 2252-6313-00 |
| XAS 25 | 2914-8021-00 | 1613-6105-00 | 2911-0040-00 |
| XAS 26 | 2914-8021-00 | 1613-6105-00 | 2911-0040-00 |
| XAS 30 | 2900-0593-00 | 1613-6105-00 | 2911-0012-00 |
| XAS 32 | 2914-8021-00 | 1613-6105-00 | 2911-0040-00 |
| XAS 35 | 2900-0593-00 | 1613-6105-00 | 2911-0014-00 |
| XAS 36 | 2914-8021-00 | 1613-6105-00 | 2911-0040-00 |
| XAS 36 - From 2003 | 2914-9302-00 | 1613-6105-00 | 2911-0105-00 |
| XAS 37 | 2914-9306-00 | 1613-6105-00 | 2911-0068-00 |
| XAS 37 K | 2914-9306-00 | 1613-6105-00 | 2911-0105-00 |
| XAS 40 | 1619-2997-00& 2900-0593-00 | 1613-6105-00 | 2911-0013-00 |
| XAS 40 D | 1619-2997-00& 2900-0593-00 | 1613-6105-00 | 1619-5498-00 |
| XAS 45 | 2900-0593-00 | 1613-6105-00 | 2911-0014-00 |
| XAS 46 | 2914-9306-00 | 1613-6105-00 | 2911-0054-00 |
| XAS 47 | 2914-9306-00 | 1613-6105-00 | 2911-0068-00 |
| XAS 47 K | 2914-9306-00 | 1613-6105-00 | 2911-0105-00 |
| XAS 50 | 1619-2997-00& 2900-0593-00 | 1613-6105-00 | 2911-0013-00 |
| XAS 50 D | 1619-2997-00& 2900-0593-00 | 1613-6105-00 | 1619-5498-00 |
| XAS 55 | 1619-2997-00 | 1613-6105-00 | 2911-0014-00 |
| XAS 56 | 2914-9306-00 | 1613-6105-00 | 2911-0054-00 |
| XAS 57 | 2914-9306-00 | 1613-6105-00 | 2911-0068-00 |
| XAS 60 | 1619-2847-00 | 1613-6105-00 | 2911-0013-00 |
| XAS 65 | 1619-2847-00 | 1613-6105-00 | 2911-0014-00 |
| XAS 66 | 2914-9308-00 | 1613-6105-00 | 2911-0068-00 |
| XAS 67 | 2914-9308-00 | 1613-6105-00 | 2911-0068-00 |
| XAS 75* | 1619-2847-00 | 1613-6105-00 | 2901-0003-00 or 2911-0015-00 |
| XAS 75 D | 1619-2847-00 | 1613-6105-00 | 1614-4373-00 |
| XAS 76 | 2914-9306-00 | 1613-6105-00 | 2911-0068-00 |
| XAS 80 | 1619-2847-00 | 1613-6105-00 | 2901-0078-00 |
| XAS 85* | 1619-2847-00 | 1613-6105-00 | 2901-0003-00 or 2911-0015-00 |
| XAS 85 D | 1619-2847-00 | 1613-6105-00 | 1614-4373-00 |
| XAS 90* | 1619-2847-00 | 1613-6105-00 | 2901-0003-00 or 2911-0015-00 |
| XAS 90 D | 1619-2847-00 | 1613-6105-00 | 1614-4373-00 |
| XAS 96 | 2914-9310-00 | 1613-6105-00 | 2911-0068-00 |
| XAS 97 | 2914-9310-00 | 1613-6105-00 | 2911-0068-00 |
| XAS 120 | 1619-2798-00 | 1613-6105-00 | 2901-0085-00 |
| XAS 125 | 1619-2798-00 | 1613-6105-00 | 2911-0016-00 |
| XAS 125 D | 1619-2798-00 | 1613-6105-00 | 2911-0028-00 |
| XAS 136 | 2914-9310-00 | 1613-6105-00 | 2911-0075-00 |
| XAS 146 | 2914-9310-00 | 1613-6105-00 | 2911-0075-00 |
| XAS 160 | 1619-2799-00 | 1613-6105-00 | 2901-0085-00 |
| XAS 175 | 1619-2799-00 | 1613-6105-00 | 2911-0016-00 |
| XAS 175 D | 1619-2799-00 | 1613-6105-00 | 1616-4656-00 |
| XAS 186 | 2914-9310-00 | 1613-6105-00 | 2911-0075-00 |
| XAS 210 | 1619-2798-00 | 1613-6105-00 | 2911-0021-00 |
| XAS 210 D | 1619-2798-00 | 1613-6105-00 | 2252-6313-01 |
| XAS 230 | 1619-2799-00 | 1613-6105-00 | 2911-0016-00 |
| XAS 280 | 1619-2798-00 | 1613-6105-00 | 2911-0017-00 |
| XAS 350 | 1619-2798-00 | 1613-6105-00 | 2911-0017-00 |
| XAS 350 D | 1619-2798-00& 1619-5545-00 | 1613-6105-00 | 2252-6313-00 |
| XAS 366 CD | 2914-5017-00& 2914-5018-00 | 1613-6105-00 | 2911-0112-00 |
| XAS 426 MD | 2914-5017-00& 2914-5018-00 | 1613-6105-00 | 2911-0117-00 |
| XAS 430 | 1619-2798-00& 1619-5545-00 | 1613-6105-00 | 2911-0017-00 |
| XAS 430 D | 1619-2798-00& 1619-5545-00 | 1613-6105-00 | 2252-6313-00 |
| XAS 495 MD | 1619-2799-00& 1619-5698-00 | 1613-6105-00 | 2911-0019-00 |
• * - Sump Tank Varies on these Models, Please Consult Dealer for Original Separator Part # Supplied
HÃNG ATLAS COPCO
Model Series: GA/GAU/GR/GX | Z-Series | Portable (XA/XAS)
GA/GAU/GR/GX Series Models
• * - For Compressors with Serial #'s 776549 and Above
• ** - For Compressors with Serial #'s 310000 and Below
| Model | Serial # | Air Filter | Oil Filter | Separator |
| GA5 | 1503-0190-00 | 1513-0337-00 | 1513-0058-00 | |
| GA5 | From 1998 | 1613-9001-00 | 1613-6105-00 | 2901-0523-00 |
| GA5 | From 119500 | 1613-9001-00 | 1613-6105-00 | 1613-9014-00 |
| GA5 | From 145000 | 1613-9001-00 | 2903-0337-00 | 2901-0523-00 |
| GA5 C | From 130000 | 1613-9001-00 | 1613-6105-00 | 1613-9014-00 |
| GA5 C | From 145000 | 1613-9001-00 | 1513-0337-00 | 2903-0871-00 |
| GA5 VSD | From 700000 | 1613-9001-00 | 2202-9295-50 | 2202-9294-50 |
| GA7 | 1503-0190-00 | 1513-0337-00 | 1513-0058-00 | |
| GA7 | From 119500 | 1613-9001-00 | 1613-6105-00 | 1613-9014-00 |
| GA7 | From 145000 | 1613-9001-00 | 2903-0337-00 | 2901-0523-00 |
| GA7 C | From 130000 | 1613-9001-00 | 1613-6105-00 | 1613-9014-00 |
| GA7 C | From 145000 | 1613-9001-00 | 1513-0337-00 | 2903-0871-00 |
| GA7 VSD | From 700000 | 1613-9001-00 | 2202-9295-50 | 2202-9294-50 |
| GA10 | 1503-0190-00 | 1513-0337-00 | 1513-0058-00 | |
| GA10 | From 119500 | 1613-9001-00 | 1613-6105-00 | 1613-9014-00 |
| GA10 | From 145000 | 1613-9001-00 | 2903-0337-00 | 2901-0523-00 |
| GA11 | 1619-1269-00 | 1613-6105-00 | 1612-3869-00 | |
| GA11 | From 1993 | 1619-1269-00 | 1613-6105-00 | 1613-6921-00 |
| GA11 | 1994 Up To 217791 | 2903-1012-00 | 1613-6105-00 | 2901-0004-01 |
| GA11 | 1995 From 217792 | 2903-1012-00 | 1613-6105-00 | 2901-0343-00 |
| GA11 | From 246349 | 1613-8720-00 | 1613-6105-00 | 1613-7502-00 |
| GA11 C | 1613-9001-00 | 1613-6105-00 | 1613-7502-00 | |
| GA11 C | From 119500 | 1613-9001-00 | 1613-6105-00 | 1613-9014-00 |
| GA11 C | From 145000 | 1613-9001-00 | 1513-0337-00 | 2903-0871-00 |
| GA11 C | From 255000 | 1613-8720-00 | 1613-6105-00 | 2901-0779-00 |
| GA11 C | From 268500 | 1613-8720-00 | 1613-6105-00 | 2901-0779-01 |
| GA11 PLUS | From 810000 | 1613-8720-00 | 1622-7836-00 | 2901-1963-00 |
| GA11 VSD | From 700000 | 1613-9001-00 | 2202-9295-50 | 2202-9294-50 |
| GA15 | 1619-1269-00 | 1613-6105-00 | 1612-3869-00 | |
| GA15 | From 1993 | 1619-1269-00 | 1613-6105-00 | 1613-6921-00 |
| GA15 | 1994 Up To 217791 | 2903-1012-00 | 1613-6105-00 | 2901-0004-01 |
| GA15 | 1995 From 217792 | 2903-1012-00 | 1613-6105-00 | 2901-0343-00 |
| GA15 | From 2000 | 1613-8720-00 | 1613-6105-00 | 1619-9720-00 |
| GA15 | From 246349 | 1613-8720-00 | 1613-6105-00 | 1613-7502-00 |
| GA15 C | From 255000 | 1613-8720-00 | 1613-6105-00 | 2901-0779-00 |
| GA15 C | From 268500 | 1613-8720-00 | 1613-6105-00 | 2901-0779-01 |
| GA15 PLUS | From 810000 | 1613-8720-00 | 1622-7836-00 | 2901-1963-00 |
| GA15 VSD | From 700000 | 1613-8720-00 | 2202-9295-50 | 2202-9294-50 |
| GA18 | 1619-1269-00 | 1613-6105-00 | 1612-3869-00 | |
| GA18 | From 1993 | 1619-1269-00 | 1613-6105-00 | 1613-6921-00 |
| GA18 | 1994 Up To 217791 | 2903-1012-00 | 1613-6105-00 | 2901-0004-01 |
| GA18 | 1995 From 217792 | 2903-1012-00 | 1613-6105-00 | 2901-0343-00 |
| GA18 | From 2000 | 1613-8720-00 | 1613-6105-00 | 1619-9720-00 |
| GA18 | From 246349 | 1613-8720-00 | 1613-6105-00 | 1613-7502-00 |
| GA18 C | From 255000 | 1613-8720-00 | 1613-6105-00 | 2901-0779-00 |
| GA18 C | From 268500 | 1613-8720-00 | 1613-6105-00 | 2901-0779-01 |
| GA18 VSD | 1613-8720-00 | 1613-6105-00 | 1622-0516-00 | |
| GA18 PLUS | From 810000 | 1613-8720-00 | 1622-7836-00 | 2901-1963-00 |
| GA22 | 1619-1269-00 | 1613-6105-00 | 1612-3869-00 | |
| GA22 | From 1993 | 1619-1269-00 | 1613-6105-00 | 1613-6921-00 |
| GA22 | 1994 Up To 217791 | 2903-1012-00 | 1613-6105-00 | 2901-0004-01 |
| GA22 | 1995 From 217792 | 2903-1012-00 | 1613-6105-00 | 2901-0343-00 |
| GA22 | From 2000 | 1613-8720-00 | 1613-6105-00 | 1619-9720-00 |
| GA22 | From 246349 | 1613-8720-00 | 1613-6105-00 | 1613-7502-00 |
| GA22 C | From 255000 | 1613-8720-00 | 1613-6105-00 | 2901-0779-00 |
| GA22 C | From 268500 | 1613-8720-00 | 1613-6105-00 | 2901-0779-01 |
| GA22 PLUS | From 268500 | 1613-8720-00 | 1613-6105-00 | 2901-0779-01 |
| GA22 PLUS | From 810000 | 1613-8720-00 | 1622-7836-00 | 2901-1963-00 |
| GA22 VSD | 297500-420963 | 1613-8720-00 | 1613-6105-00 | 1622-0516-00 |
| GA26 PLUS | From 810000 | 1613-8720-00 | 1622-7836-00 | 2901-1963-00 |
| GA30 | 1619-2997-00 | 1613-6105-00 | 1202-6414-00 | |
| GA30 | From 1994 | 1613-7407-00 | 1613-6105-00 | 1613-6880-00 |
| GA30 | 1994 Up To 315329 | 1619-2997-00 | 1613-6105-00 | 2901-0213-00 |
| GA30 | From 315330 | 1613-7407-00 | 1613-6105-00 | 2901-0213-00 |
| GA30 | 1998 From 360000 | 1613-7407-00 | 1613-6105-00 | 2901-0566-00 |
| GA30 | From 810000 | 1613-8720-00 | 1622-7836-00 | 2901-1963-00 |
| GA30 C | From 2000 | 1613-8720-00 | 1613-6105-00 | 1619-9720-00 |
| GA30 C | From 255000 | 1613-8720-00 | 1613-6105-00 | 2901-0779-00 |
| GA30 C | From 268500 | 1613-8720-00 | 1613-6105-00 | 2901-0779-01 |
| GA30 PLUS | From 507438 | 1613-7408-00 | 1622-3142-80 or 1622-5072-80 | 2901-1626-00 |
| GA30 PLUS | 2006 From 591000 | 1613-7407-00 | 1622-3142-80 or 1622-5072-80 | 2901-1643-00 |
| GA30 VSD | 1613-7408-00 | 1613-6105-00 | 1613-8397-00 | |
| GA37 | 1619-2997-00 | 1613-6105-00 | 1202-6414-00 | |
| GA37 | From 1994 | 1613-7407-00 | 1613-6105-00 | 1613-6880-00 |
| GA37 | 1994 Up To 315329 | 1619-2997-00 | 1613-6105-00 | 2901-0213-00 |
| GA37 | From 315330 | 1613-7407-00 | 1613-6105-00 | 2901-0213-00 |
| GA37 | 1998 From 360000 | 1613-7407-00 | 1613-6105-00 | 2901-0566-00 |
| GA37 | 2006 From 591000 | 1613-7407-00 | 1622-3142-80 or 1622-5072-80 | 2901-1643-00 |
| GA37 - 7.5 Bar | 1613-7408-00 | 1613-6105-00 | 1613-8397-00 | |
| GA37 - 10 Bar | 1613-7407-00 | 1613-6105-00 | 2901-1389-00 | |
| GA37 - 13 Bar | 1613-7407-00 | 1613-6105-00 | 2901-0566-00 | |
| GA37 PLUS | From 507438 | 1613-7408-00 | 1622-3142-80 or 1622-5072-80 | 2901-1626-00 |
| GA37 VSD | 1613-7408-00 | 1613-6105-00 | 1613-8397-00 | |
| GA37 VSD | From 572446 | 1613-7408-00 | 1622-3142-80 or 1622-5072-80 | 1622-3140-00 |
| GA45 | 1619-2847-00 | 1613-6105-00 | 1202-7419-00 | |
| GA45 | From 1994 | 1619-2847-00 | 1613-6105-00 | 1613-6880-00 |
| GA45 | From 1995 | 1613-7408-00 | 1613-6105-00 | 1613-7306-00 |
| GA45 | 1994 Up To 315329 | 1619-2847-00 | 1613-6105-00 | 2901-0213-00 |
| GA45 | From 315330 | 1613-7408-00 | 1613-6105-00 | 2901-0213-00 |
| GA45 | 1998 From 360000 | 1613-7408-00 | 1613-6105-00 | 2901-0566-00 |
| GA45 | 2006 From 591000 | 1613-7407-00 | 1622-3142-80 or 1622-5072-80 | 2901-1643-00 |
| GA45 - 7.5 Bar | 1613-7408-00 | 1613-6105-00 | 1613-8397-00 | |
| GA45 - 10 Bar | 1613-7408-00 | 1613-6105-00 | 2901-1389-00 | |
| GA45 - 13 Bar | 1613-7407-00 | 1613-6105-00 | 2901-0566-00 | |
| GA45 PLUS | From 507438 | 1613-7408-00 | 1622-3142-80 or 1622-5072-80 | 2901-1626-00 |
| GA45 VSD | FRom 572446 | 1613-7408-00 | 1622-3142-80 or 1622-5072-80 | 1622-3140-00 |
| GA50 | 1998 From 350000 | 1613-7408-00 | 1613-6105-00 | 2901-0566-00 |
| GA50 VSD | 1613-7408-00 | 1613-6105-00 | 1613-8397-00 | |
| GA55 | 1619-2798-00 | 1613-6105-00 | 1202-7419-00 | |
| GA55 | From 1995 | 1613-7408-00 | 1613-6105-00 | 1613-7306-00 |
| GA55 | 1996 From 460001 | 1613-7408-00 | 1613-6105-00 | 1613-8007-00 |
| GA55 | From 2000 | 1613-9501-00 | 1613-6105-00 | 1613-9559-00 |
| GA55 | From 507438 | 1622-1855-01 | 1622-3142-80 or 1622-5072-80 | 2901-1626-00 |
| GA55 C | 1613-7408-00 | 1613-6105-00 | 1613-8007-00 | |
| GA55 C | From 471000 | 1613-9501-00 | 1613-6105-00 | 1613-9559-00 |
| GA55 PLUS | From 2005 | 1613-9503-00 | 1622-3652-80 or 1622-4601-80 | 2901-0566-22 |
| GA55 VSD | From 572446 | 1622-1855-01 | 1622-3142-80 or 1622-5072-80 | 2901-1626-00 |
| GA75 | 1613-9501-00 | 1613-6105-00 | 1202-7419-00 | |
| GA75 | From 1995 | 1613-7408-00 | 1613-6105-00 | 1613-7306-00 |
| GA75 | 1996 From 460001 | 1613-8004-00 | 1613-6105-00 | 1613-8007-00 |
| GA75 | From 2000 | 1613-9503-00 | 1613-6105-00 | 1613-9840-00 |
| GA75 | From 471000 | 1613-9503-00 | 1613-6105-00 | 2901-0858-00 |
| GA75 | From 507438 | 1622-1855-01 | 1622-3142-80 or 1622-5072-80 | 2901-1626-10 |
| GA75 C | From 474000 | 1613-9503-00 | 1613-6105-00 | 2901-0858-00 |
| GA75 PLUS | From 2005 | 1613-9503-00 | 1622-3652-80 or 1622-4601-80 | 2901-0566-22 |
| GA75 VSD | 1613-9503-00 | 1622-3652-80 or 1622-4601-80 | 1613-9840-00 | |
| GA75 VSD | From 493000 | 1613-9503-00 | 1613-6105-00 | 1613-9559-00 and 1613-7277-00 |
| GA90 | 1030-0979-00 | 1613-6105-00 | 1614-6423-00 | |
| GA90 | 1999 From 056813 | 1621-0547-00 | 1613-6105-00 | 2906-0564-00 |
| GA90 PLUS | From 2005 | 1613-9503-00 | 1622-3652-80 or 1622-4601-80 | 2901-0566-22 |
| GA90 | From 2006 | 1613-9503-00 | 1622-3652-80 or 1622-4601-80 | 2906-0751-00 |
| GA90 - 5.2-5.5 Bar | From 2008 | 1621-7376-00 | 1621-7378-00 | 2906-0956-00 |
| GA90 - 6.9-8.6 Bar | From 2008 | 1621-7376-00 | 1621-7378-00 | 2906-0955-00 |
| GA90 - 10-14 Bar | From 2008 | 1621-7376-00 | 1621-7378-00 | 2906-0954-00 |
| GA90 C | 1613-8004-00 | 1613-6105-00 | 1613-8007-00 | |
| GA90 C | From 474000 | 1613-9503-00 | 1613-6105-00 | 2901-0858-00 |
| GA90 VSD | 1613-9503-00 | 1622-3652-80 or 1622-4601-80 | 2901-0566-22 | |
| GA90 VSD | From 493000 | 1613-9503-00 | 1613-6105-00 | 1613-9559-00 and 1613-7277-00 |
| GA100 | 1619-1269-00 | 1613-6105-00 | 2901-0003-00 | |
| GA110 | 1030-0979-00 | 1613-6105-00 | 1614-6423-00 | |
| GA110 | 1999 From 056813 | 1621-0547-00 | 1613-6105-00 | 2906-0564-00 |
| GA110 | From 2006 | 1621-0547-00 | 1613-6105-00 | 2906-0751-00 |
| GA110 | From 2008 | 1621-7376-00 | 1621-7378-00 | 1623-0515-00 |
| GA110 - 10-14 Bar | From 2008 | 1621-7376-00 | 1621-7378-00 | 1623-0516-00 |
| GA110 PLUS | From 2008 | 1621-7376-00 | 1621-7378-00 | 2906-0955-00 |
| GA110 PLUS 10-14 Bar | From 2008 | 1621-7376-00 | 1621-7378-00 | 2906-0954-00 |
| GA111 up to 122 | 1619-1269-00 | 1613-6105-00 | 1612-3869-00 | |
| GA132 | 1030-0979-00 | 1613-6105-00 | 1614-6423-00 | |
| GA132 | 1999 From 056813 | 1621-0547-00 | 1613-6105-00 | 2906-0565-00 |
| GA132 | From 2006 | 1621-5742-00 | 1613-6105-00 | 2906-0752-00 |
| GA132 - 5.2-5.5 Bar | From 2008 | 1621-7376-00 | 1621-7378-00 | 2906-0956-00 |
| GA132 - 6.9-8.6 Bar | From 2008 | 1621-7376-00 | 1621-7378-00 | 2906-0955-00 |
| GA132 - 10-14 Bar | From 2008 | 1621-7376-00 | 1621-7378-00 | 2906-0954-00 |
| GA160 | 1030-0979-00 | 1613-6105-00 | 1614-6423-00 | |
| GA160 | 1999 From 056813 | 1621-0547-00 | 1613-6105-00 | 2906-0565-00 |
| GA160 | From 2006 | 1621-5742-00 | 1613-6105-00 | 2906-0752-00 |
| GA160 - 5.2-5.5 Bar | From 2008 | 1621-7376-00 | 1621-7378-00 | 2906-0956-00 |
| GA160 - 6.9-8.6 Bar | From 2008 | 1621-7376-00 | 1621-7378-00 | 2906-0955-00 |
| GA160 - 10-14 Bar | From 2008 | 1621-7376-00 | 1621-7378-00 | 2906-0954-00 |
| GA180 VSD | 1621-0547-00 | 1613-6105-00 | 1614-9056-00 | |
| GA180 VSD | From 2006 | 1621-5742-00 | 1613-6105-00 | 2906-0752-00 |
| GA200 | 1030-0979-00 | 1614-7273-00 | 1614-7048-00 | |
| GA200 | From 1999 | 1621-0547-00 | 1613-6105-00 | 1614-9056-00 |
| GA200 | From 2000 | 1621-0547-00 | 1614-7273-00 | 2906-0588-00 |
| GA200 | From 2006 | 1621-5742-00 | 1614-7273-00 | 2906-0753-00 |
| GA200 | From 2008 | 1621-5107-00 | 1614-7273-00 | 1621-9386-00 |
| GA207 up to 210 | 1030-1070-00 | 1613-6105-00 | 1613-2433-00 | |
| GA230 | 1619-2997-00 | 1613-6105-00 | 1614-5329-00 | |
| GA237 | 1619-2997-00 | 1613-6105-00 | 1614-5329-00 | |
| GA250 | 1030-0979-00 | 1614-7273-00 | 1614-7048-00 | |
| GA250 | 1619-2798-00 | 1614-8065-00 | 2906-0588-00 | |
| GA307 up to 310 | 1030-1070-00 | 1613-6105-00 | 1613-2433-00 | |
| GA315 | 1030-0979-00 | 1614-7273-00 | 1614-7048-00 | |
| GA315 | From 2000 | 1621-0547-00 | 1614-7273-00 | 2906-0588-00 |
| GA315 | From 2006 | 1621-5742-00 | 1614-7273-00 | 2906-0753-00 |
| GA315 VSD | 1621-0547-00 | 1614-7273-00 | 2906-0588-00 | |
| GA315 VSD | From 2006 | 1621-5742-00 | 1614-7273-00 | 2906-0753-00 |
| GA345 | 1619-2847-00 | 1613-6105-00 | 1202-8343-00 | |
| GA355 | 1619-2798-00 | 1613-6105-00 | 1202-8343-00 | |
| GA375 | 1619-2798-00 | 1613-6105-00 | 1202-8343-00 | |
| GA407 up to 410 | 1030-1070-00 | 1613-6105-00 | 1613-2433-00 | |
| GA450 | 1621-0547-00 | 1614-7273-00 | 1613-9521-00 | |
| GA450 | From 2006 | 1621-5742-00 | 1613-6105-00 | 2906-0753-00 |
| GA507 up to 510 | 1030-1070-00 | 1613-6105-00 | 2901-0078-00 | |
| GA607 upto 710 | 1030-1070-00 | 1613-6105-00 | 2901-0085-00 | |
| GA807 up to 1110 | 1621-0547-00 | 1613-6105-00 | 2906-0020-00 | |
| GA1207 up to 1410 | 1621-0547-00 | 1613-6105-00 | 2911-0017-00 | |
| GAH 115 | 1619-1269-00 | 1613-6105-00 | 2901-0003-00 | |
| GAH 118 | 1619-1269-00 | 1613-6105-00 | 2901-0003-00 | |
| GAH 122 | 1619-1269-00 | 1613-6105-00 | 2901-0003-00 | |
| GAU15 up to 40 | 1619-1269-00 | 1310-0940-83 | 2901-0003-00 | |
| GAU307 up to 509 | 1030-1070-00 | 1613-6105-00 | 2901-0078-00 | |
| GAU607 up to 709 | 1030-1070-00 | 1613-6105-00 | 2901-0085-00 | |
| GAU807 up to 1409 | 1621-0547-00 | 1613-6105-00 | 2906-0020-00 | |
| GR110 up to 200 | 1621-0547-00 | 1202-8040-00 | 2906-0638-00 | |
| GR110 up to 200 | From 085972 | 1621-0547-00 | 1202-8040-00 | 1621-9387-00 |
| GR620 | 1030-1070-00 | 1202-8040-00 | 2901-0078-00 | |
| GR1120 | 1621-0547-00 | 1202-8040-00 | 2906-0020-00 | |
| GR1520 | 1621-0547-00 | 1202-8040-00 | 2911-0017-00 | |
| GX2 | 1622-0658-00 | 1513-0337-00 | 2903-0623-01 | |
| GX3 | 1622-0658-00 | 1513-0337-00 | 2903-0623-01 | |
| GX4 | 1622-0658-00 | 1513-0337-00 | 2903-0623-01 | |
| GX5 | 1613-9001-00 | 1613-6105-00 | 1622-0245-00 | |
| GX5 | Up to 619999 | 1613-9001-00 | 1513-0337-00 | 2903-0871-00 |
| GX5 | From 620000 | 1613-9001-00 | 1613-6105-00 | 2903-0871-00 |
| GX7 | 1613-9001-00 | 1613-6105-00 | 1622-0245-00 | |
| GX7 | Up to 619999 | 1613-9001-00 | 1513-0337-00 | 2903-0871-00 |
| GX7 | From 620000 | 1613-9001-00 | 1613-6105-00 | 2903-0871-00 |
| GX11 | 1613-9001-00 | 1613-6105-00 | 1622-0245-00 | |
| GX11 | Up to 619999 | 1613-9001-00 | 1513-0337-00 | 2903-0871-00 |
| GX11 | From 620000 | 1613-9001-00 | 1613-6105-00 | 2903-0871-00 |
| GX15 | 1613-8720-00 | 1613-6105-00 | 2903-0351-01 | |
| GX18 | 1613-8720-00 | 1613-6105-00 | 2903-0351-01 | |
| GX22 | 1613-8720-00 | 1613-6105-00 | 2903-0351-01 |
• * - For Compressors with Serial #'s 776549 and Above
• ** - For Compressors with Serial #'s 310000 and Below
Z-Series Models:
• * - If Compressor Has Spin-On Type Oil Filter, Replacement Part # is 1613-6105-00
| Model | Air Filter | Oil Filter | 4000 HR Kit | 8000 HR Kit |
| ZA3 | 1030-1070-00 | 1619-0355-00 | 2906-0278-00 | 2906-0279-00 |
| ZA4 | 1030-0979-00 | 1619-0355-00* | 2906-0270-00 | 2906-0271-00 |
| ZA5 | 1030-0979-00 | 1613-6105-00 | 2906-0258-00 | 2906-0264-00 |
| ZA6 | 1030-0979-00 | 1613-6105-00 | 2906-0258-00 | 2906-0259-00 |
| ZR3 | 1030-1070-00 | 1619-0355-00 | 2906-0111-00 | 2906-0112-00 |
| ZR4 | 1030-0979-00 | 1619-0355-00* | 2906-0084-00 | 2906-0085-00 |
| ZR5 | 1030-0979-00 | 1613-6105-00 | 2906-0149-00 | 2906-0150-00 |
| ZR6 | 1030-0979-00 | 1613-6105-00 | 2906-0135-00 | 2906-0136-00 |
| ZR45 | 2900-0582-00 | 1619-6227-00 | 2906-0194-00 | N/A |
| ZR55 | 2900-0582-00 | 1619-6227-00 | 2906-0194-00 | N/A |
| ZR75 | 1619-2799-00 | 1619-6227-00 | N/A | N/A |
| ZR90 | 1619-2799-00 | 1619-6227-00 | N/A | N/A |
| ZR110 | 1030-0979-00 | 1621-0270-00 | N/A | N/A |
| ZR132 | 1030-0979-00 | 1621-0270-00 | N/A | N/A |
| ZR145 | 1030-0979-00 | 1621-0270-00 | N/A | N/A |
| ZR160 | 1621-0094-00 | 1621-0270-00 | N/A | N/A |
| ZR200 | 1621-0094-00 | 1621-0270-00 | N/A | N/A |
| ZR250 | 1621-0094-00 | 1621-0270-00 | N/A | N/A |
| ZR275 | 1621-0094-00 | 1621-0270-00 | N/A | N/A |
| ZR450 | 1621-0094-00 | 1621-0270-00 | N/A | N/A |
| ZR500 | 1621-0094-00 | 1621-0270-00 | N/A | N/A |
| ZR630 | 1621-0094-00 | 1621-0270-00 | N/A | N/A |
| ZR750 | 1621-0094-00 | 1621-0270-00 | N/A | N/A |
| ZT3 | 1030-1070-00 | 1619-0355-00 | N/A | N/A |
| ZT4 | 1030-0979-00 | 1619-0355-00* | N/A | N/A |
| ZT45 | 2900-0582-00 | 1619-6227-00 | 2906-0194-00 | N/A |
| ZT55 | 2900-0582-00 | 1619-6227-00 | 2906-0194-00 | N/A |
| ZT75 | 1619-2799-00 | 1619-6227-00 | N/A | N/A |
| ZT90 | 1619-2799-00 | 1619-6227-00 | N/A | N/A |
| ZT237 | 2900-0582-00 | 1619-6227-00 | N/A | N/A |
| ZT245 | 2900-0582-00 | 1619-6227-00 | N/A | N/A |
| ZT255 | 2900-0582-00 | 1619-6227-00 | N/A | N/A |
| ZT275 | 2900-0582-00 | 1619-6227-00 | N/A | N/A |
| ZT290 | 2900-0582-00 | 1619-6227-00 | N/A | N/A |
• * - If Compressor Has Spin-On Type Oil Filter, Replacement Part # is 1613-6105-00
Portable Models (XA/XAS):
• * - Sump Tank Varies on these Models, Please Consult Dealer for Original Separator Part # Supplied
| Model | Air Filter | Oil Filter | Separator |
| XA 30 | 2900-0593-00 | 1613-6105-00 | 2911-0012-00 |
| XA 35 | 2900-0593-00 | 1613-6105-00 | 2911-0014-00 |
| XA 40 | 2900-0593-00 | 1613-6105-00 | 2911-0013-00 |
| XA 40 D | 2900-0593-00 | 1613-6105-00 | 1619-5498-00 |
| XA 45 | 2900-0593-00 | 1613-6105-00 | 2911-0014-00 |
| XA 50 | 1619-2997-00 | 1613-6105-00 | 2911-0013-00 |
| XA 50 D | 1619-2997-00 | 1613-6105-00 | 1619-5498-00 |
| XA 55 | 1619-2997-00 | 1613-6105-00 | 2911-0014-00 |
| XA 60 | 1619-2847-00 | 1613-6105-00 | 2911-0013-00 |
| XA 65 | 1619-2847-00 | 1613-6105-00 | 2911-0014-00 |
| XA 70 | 1619-2847-00 | 1613-6105-00 | 2911-0014-00 |
| XA 75 | 1619-2847-00 | 1613-6105-00 | 2911-0015-00 |
| XA 80 | 1619-2847-00 | 1613-6105-00 | 2901-0078-00 |
| XA 85 | 1619-2847-00 | 1613-6105-00 | 2911-0015-00 |
| XA 90 | 1619-2847-00 | 1613-6105-00 | 2911-0015-00 |
| XA 120 | 1619-2798-00 | 1613-6105-00 | 2901-0085-00 |
| XA 125 | 1619-2798-00 | 1613-6105-00 | 2911-0016-00 |
| XA 125 D | 1619-2799-00 | 1613-6105-00 | 1616-4656-00 |
| XA 160 | 1619-2799-00 | 1613-6105-00 | 2901-0085-00 |
| XA 175 | 1619-2798-00 | 1613-6105-00 | 2911-0016-00 |
| XA 175 D | 1619-2799-00 | 1613-6105-00 | 1616-4656-00 |
| XA 210 | 1619-2798-00 | 1613-6105-00 | 2911-0021-00 |
| XA 210 D | 1619-2798-00 | 1613-6105-00 | 2252-6313-01 |
| XA 250 | 1619-2798-00 | 1613-6105-00 | 2901-0085-00 |
| XA 350 | 1619-2798-00 | 1613-6105-00 | 2911-0017-00 |
| XA 350 D | 1619-2798-00 | 1613-6105-00 | 2252-6313-00 |
| XAS 25 | 2914-8021-00 | 1613-6105-00 | 2911-0040-00 |
| XAS 26 | 2914-8021-00 | 1613-6105-00 | 2911-0040-00 |
| XAS 30 | 2900-0593-00 | 1613-6105-00 | 2911-0012-00 |
| XAS 32 | 2914-8021-00 | 1613-6105-00 | 2911-0040-00 |
| XAS 35 | 2900-0593-00 | 1613-6105-00 | 2911-0014-00 |
| XAS 36 | 2914-8021-00 | 1613-6105-00 | 2911-0040-00 |
| XAS 36 - From 2003 | 2914-9302-00 | 1613-6105-00 | 2911-0105-00 |
| XAS 37 | 2914-9306-00 | 1613-6105-00 | 2911-0068-00 |
| XAS 37 K | 2914-9306-00 | 1613-6105-00 | 2911-0105-00 |
| XAS 40 | 1619-2997-00& 2900-0593-00 | 1613-6105-00 | 2911-0013-00 |
| XAS 40 D | 1619-2997-00& 2900-0593-00 | 1613-6105-00 | 1619-5498-00 |
| XAS 45 | 2900-0593-00 | 1613-6105-00 | 2911-0014-00 |
| XAS 46 | 2914-9306-00 | 1613-6105-00 | 2911-0054-00 |
| XAS 47 | 2914-9306-00 | 1613-6105-00 | 2911-0068-00 |
| XAS 47 K | 2914-9306-00 | 1613-6105-00 | 2911-0105-00 |
| XAS 50 | 1619-2997-00& 2900-0593-00 | 1613-6105-00 | 2911-0013-00 |
| XAS 50 D | 1619-2997-00& 2900-0593-00 | 1613-6105-00 | 1619-5498-00 |
| XAS 55 | 1619-2997-00 | 1613-6105-00 | 2911-0014-00 |
| XAS 56 | 2914-9306-00 | 1613-6105-00 | 2911-0054-00 |
| XAS 57 | 2914-9306-00 | 1613-6105-00 | 2911-0068-00 |
| XAS 60 | 1619-2847-00 | 1613-6105-00 | 2911-0013-00 |
| XAS 65 | 1619-2847-00 | 1613-6105-00 | 2911-0014-00 |
| XAS 66 | 2914-9308-00 | 1613-6105-00 | 2911-0068-00 |
| XAS 67 | 2914-9308-00 | 1613-6105-00 | 2911-0068-00 |
| XAS 75* | 1619-2847-00 | 1613-6105-00 | 2901-0003-00 or 2911-0015-00 |
| XAS 75 D | 1619-2847-00 | 1613-6105-00 | 1614-4373-00 |
| XAS 76 | 2914-9306-00 | 1613-6105-00 | 2911-0068-00 |
| XAS 80 | 1619-2847-00 | 1613-6105-00 | 2901-0078-00 |
| XAS 85* | 1619-2847-00 | 1613-6105-00 | 2901-0003-00 or 2911-0015-00 |
| XAS 85 D | 1619-2847-00 | 1613-6105-00 | 1614-4373-00 |
| XAS 90* | 1619-2847-00 | 1613-6105-00 | 2901-0003-00 or 2911-0015-00 |
| XAS 90 D | 1619-2847-00 | 1613-6105-00 | 1614-4373-00 |
| XAS 96 | 2914-9310-00 | 1613-6105-00 | 2911-0068-00 |
| XAS 97 | 2914-9310-00 | 1613-6105-00 | 2911-0068-00 |
| XAS 120 | 1619-2798-00 | 1613-6105-00 | 2901-0085-00 |
| XAS 125 | 1619-2798-00 | 1613-6105-00 | 2911-0016-00 |
| XAS 125 D | 1619-2798-00 | 1613-6105-00 | 2911-0028-00 |
| XAS 136 | 2914-9310-00 | 1613-6105-00 | 2911-0075-00 |
| XAS 146 | 2914-9310-00 | 1613-6105-00 | 2911-0075-00 |
| XAS 160 | 1619-2799-00 | 1613-6105-00 | 2901-0085-00 |
| XAS 175 | 1619-2799-00 | 1613-6105-00 | 2911-0016-00 |
| XAS 175 D | 1619-2799-00 | 1613-6105-00 | 1616-4656-00 |
| XAS 186 | 2914-9310-00 | 1613-6105-00 | 2911-0075-00 |
| XAS 210 | 1619-2798-00 | 1613-6105-00 | 2911-0021-00 |
| XAS 210 D | 1619-2798-00 | 1613-6105-00 | 2252-6313-01 |
| XAS 230 | 1619-2799-00 | 1613-6105-00 | 2911-0016-00 |
| XAS 280 | 1619-2798-00 | 1613-6105-00 | 2911-0017-00 |
| XAS 350 | 1619-2798-00 | 1613-6105-00 | 2911-0017-00 |
| XAS 350 D | 1619-2798-00& 1619-5545-00 | 1613-6105-00 | 2252-6313-00 |
| XAS 366 CD | 2914-5017-00& 2914-5018-00 | 1613-6105-00 | 2911-0112-00 |
| XAS 426 MD | 2914-5017-00& 2914-5018-00 | 1613-6105-00 | 2911-0117-00 |
| XAS 430 | 1619-2798-00& 1619-5545-00 | 1613-6105-00 | 2911-0017-00 |
| XAS 430 D | 1619-2798-00& 1619-5545-00 | 1613-6105-00 | 2252-6313-00 |
| XAS 495 MD | 1619-2799-00& 1619-5698-00 | 1613-6105-00 | 2911-0019-00 |
• * - Sump Tank Varies on these Models, Please Consult Dealer for Original Separator Part # Supplied
